HSSL Screw Conveyor
• It is mainly used for the level or gradient conveying of stock. Screw conveyor’ s ambient temperature is -20〜50℃; stock temperature is below 200 °C; gradient:β≤20°. The conveying length is generally shorter than 40 meters, maximally 70 meters.
• Made of high grade carbon Steel.
• With reducer.
• With anti-block system to ensure work safety.
Technical specification
| Model | Diameter of screw (mm) | Pitch (mm) | Rotating speed (r/min) | Capacity (t/h) | |
| wheat | flour | ||||
| HSSL16 | 160 | 160 | 60-160 | 2.5-6 | 0.8-2.0 |
| HSSL20 | 200 | 200 | 60-140 | 2.5-6 | 0.8-2.0 |
| HSSL25 | 250 | 250 | 60-120 | 2.5-6 | 0.8-2.0 |
| HSSL 32 | 320 | 320 | 60-110 | 2.5-6 | 0.8-2.0 |
| HSSL40 | 400 | 350 | 60-100 | 2.5-6 | 0.8-2.0 |
| HSSL50 | 500 | 400 | 60-80 | 2.5-6 | 0.8-2.0 |
