Sizer(JJSD)
JJSD sizerhas a compact structure, digital readout, precise timing control, convenient operation. It is widely used in the screening and testing of grain and oil seed.
Technical specification
| Max. sieving quantity | 500g |
| Decks | 3 layers |
| Swing diameter | 100mm |
| Rotating speed | 120r/min |
| Clockwise rotation time and counter clockwise rotation time | Both are 60s (digital readout) |
| Sieve frame outer diameter | 220mm |
| Motor power | 60W |
| Working voltage | AC220V |
| Total weight | 22kg |
| Dimension | 400mm × 400mm × 200mm |
