• SZLH series C type ring die pellet mill reaches international advanced level; it has the latest technology and low breakdown rate;
• On the base of Type B pellet mill, steam conditioning device and variable speed motor are added to raw material conveying to control the feeding; the feeding is steady and reliable;
• Enlarged stainless steel steam conditioner can provide long time conditioning and curing;
• Single-layer, dual-layer and multiple-layer jacket conditioner or double-shaft differential diameter conditioner can be configured to meet different production demands of high grade livestock and poultry feeds and aquatic feeds.
• Drive mechanism adopts high strength belt; with steady running and low noise;
• Drive mechanism adopts high quality bearing to ensure high speed and stable operation;
• Feeding part is equipped with a permanent magnet to remove metallic impurities; this prolongs the service life of main parts and meanwhile, reduces the use of auxiliary equipment;
• Convenient operation, reliable sealing, high production rate, 低功耗, low labor strength.
技术规格
| 范围 | SZLH20C | SZLH25C | SZLH30C | SZLH35C |
| Production rate(公斤/小时) | 600-800 | 1000-2000 | 1500-2500 | 3000-4000 |
| Main motor power(千瓦) | 11 | 22 | 30 | 37 |
| Feeding and conditioning motor power(千瓦) | 0.75+1.1 | 0.75+1.1 | 0.75+1.1 | 0.75+1.5 |
| Ring die speed(转速) | 306 | 306 | 330 | 306 |
| Ring die’s inner diameter(毫米) | 200 | 250 | 304 | 350 |
| Ring die specification(毫米) | Φ1.5, Φ2, Φ2.5, Φ3, Φ3.5, Φ4, Φ5, Φ6, Φ8 | |||
| Dimensions(毫米) | 1.1*1.86*1.6 | 1.1*1.86*1.6 | 1.35*1.88*1.65 | 1.5*1.3*1.8 |
| 重量(公斤) | 720 | 900 | 1035 | 1200 |
