振动分级筛
• It is used for the final process of pelletizing stage in small and medium-scaled feed mills. The feed pellets, after being pelletized orcrushed, will be sifted to extract qualified granular feed product. Unqualified large and small pellets and powder will be sifted out and return to pellet mill for pelletizing again;
• It has many features such as simple structure, 操作简单, convenient maintenance, 低功耗, 低噪声, good sealing, no pollution;
• It is widely used for the pre-cleaning and sifting in feed, grain and chemical industries, ETC.
技术规格
范围 | SFJZ80*2 | SFJZ100*2 | |
Production rate (吨/小时) | 1-5 | 5-10 | |
力量 (千瓦) | 0.25*2 | 0.25*2 | |
Vibro frequency (times/min) | 920 | 920 | |
Vibro force range (n) | 0-3000 | 0-5000 | |
Amplitude (毫米) | 2.5-4 | 2.5-4 | |
Screen size | Upper | 630*1220 | 1000*1590 |
Lower | 630*1050 | 1000*1350 | |
Screen’s tilting angle | 30° | 30° | |
Screen layer | 2 | 2 | |
风量 (立方米/分钟) | 5 | 10 | |
尺寸 (毫米) | 1750*1300*1750 | 2030*1400*2000 | |
重量 (公斤) | 350 | 430 |
